THD<3% under standard load
Multiple protection for safer use
300% surge Rating (20s)
Suitable for multiple batteries
Suitable for vehicle systems
- Pure sine wave output. The conversion efficiency is up to 92%. The conventional conversion time is 6ms. It can hold 300% overload within 20s, providing necessary current for starting electrical appliances with high requirements. AP series can realize the function of starting/stopping the generator, monitoring the equipment operation status and battery temperature etc. by mobile through additional communication modules.
TECHNICAL PARAMETER
AP Series
DC operating voltage：12V / 24V / 48V
AC operating voltage：single phase 100-110-120V/
220-230-240V，Split phase 120V/230V（Models
above 3KW）
Operating frequency：50Hz/60Hz
Range of power：1.0KW/1.5KW/2.0KW/3.0KW/4.0KW
/5.0KW/6.0KW
